Paket Pro Sound Groundstack Array Logic System

( Small to Medium setup )

Sistem terdiri dari :

• 4 Unit : Speaker Line Array Logic System
• 2 Unit : Subwoofer Pasif Logic System
• 1 Unit : Mixer Soundcraft
• 1 Unit : Speaker Management DBX
• 1 Unit : Equalizer Grafis DBX
• 1 Unit : Power Amplifier Crown Audio
• 1 Unit : Power Amplifier QSC
• 1 Set : Mic Wireless Sennheiser
• 2 Unit : Stand Speaker
• 1 Lot : Kabel Mic & Kabel Speaker

Solusi sistem tata suara portabel skala menengah berkualitas premium untuk berbagai aplikasi seperti :

– Portable DJ
– Atrium Mall
– Auditorium (dengan dimensi ruangan memanjang ke belakang)

Desain solusi sound system ideal berstandar kualitas tinggi dan tepat guna dari kami untuk anda.

Speaker Line Array Logic System

• Frequency Response: 100Hz – 20kHz (With assisted alignment)
• Components: Bass/mid: 1 off 8″ neodymium cone drivers ,HF: 2 off 1″ exit neodymium compression driver
• Power Handling: 250w (Per Cabinet)
• Sensitivity (1): 103dB (Minimum two box configuration)
• Directivity: 90 x 20 above 1kHz
• Impedance: 16 Ohm
• Construction: 15mm Birch plywood
• Finish: Water based textured black paint
• Connections: 2 x Neutrik NL4 connectors (1+/1- input 2+/2- n/c )
• Dimensions: 505mm (W) x 255mm (H) x 300mm (D)
• Packaged Dimensions (2): 640mm (W) x 680mm (H) x 420mm (D)
• Weight: 15 KG

Subwoofer Passive Logic System

• Frequency Response: 40Hz – 150Hz
• Components:
• Bass: 2 x 15″ cone drivers
• HF: N/A
• Power Handling: 2000w
• Sensitivity (1): 102dB
• Directivity: Omni-directional
• Impedance: 4 Ohm
• Construction: 18mm Birch plywood
• Finish: Water based textured black paint
• Connections: 2 x Neutrik NL4 (Main input:) 1+/-bass, 2+/- CA input  1 X Neutrik NL4 (CA output:), 1+/-, 2+/- NC
• Note: CA output fed from main input 2+/-
• Dimensions: 505mm (W) X 780mm (H) X 600mm (D)
• Packaged Dimensions (2): 635mm (W) X 930mm (H) X 730mm (D)
• Weight: 57 KG (Dolly: 8 KG)

Mixer Soundcraft

Features:

• 12+2 channel frame size
• Built-in 24 bit Lexicon digital effects processor
• 32 effects settings
• Tap tempo and effects setting store function
• One effects send on each channel
• One configurable auxiliary bus
• XLR-type and 1/4″ metal jack connector sockets
• RCA phono stereo playback inputs and record outputs
• 3-band EQ with a swept mid on mono inputs
• 3-band EQ on stereo inputs
• TRS insert sockets and inserts on all mono inputs
• Ten-segment LED output metering
• Intuitive and comprehensive solo system
• Headphone output
• Easily rackmountable

Speaker Manajemen DBX

Features:

• Feedback elimination
• 2.7 seconds of Alignment and Zone Delay
• RS-232 PC GUI control
• Classic dbx Compression and Limiting
• Graphic and Parametric EQ
• Auto-EQ function
• Full Bandpass, Crossover, and Routing configurations
• Auto Gain control
• Pink Noise Generator and fulltime RTA
• Set-up Wizard with JBL speaker and Crown Power Amp tunings
• Security lockout
• Wall Panel Control inputs

Equalizer Grafis DBX

Features at  :

• 1/3-octave Constant Q frequency bands
• Switchable boost/cut ranges of +/-6 or +/-12dB
• 12dB/octave 50Hz low-cut filter
• Front panel bypass switch
• +/-12dB input gain range
• 4-segment LED ladders for monitoring output level
• XLR and TRS inputs and outputs
• Frequency response of <10Hz to >50kHz
• Dynamic range of greater than 108dB
• Weight: 6.2 lbs.
• Dimensions: 3.5″ x 6″ x 19″

Power Crown Audio

Features:

• An affordable and reliable power amplifier you can use in any PA system
• 2,700-watts in bridged-mono mode, up to 1350-watts stereo/parallel operation
• Includes both unbalanced RCA and balanced XLR input connectivity
• Binding post and speakON output connectors let you use virtually any passive PA speakers
• Selectable input voltage (.755V or 1.4V) lets you set up your rig to match your gear
• LED power, fault, signal-presence, and clip indicators let you keep an eye on the safety of your amplifier
• Forced-air cooling and protection against shorts, no-load, and on/off thumps ensure smooth operation and long life
• Excellent shielding against radio-frequency interference keeps your sound clean, even in heavy wireless conditions

Power Amplifier QSC

FEATURES

• 8 ohms, Stereo Mode, Both Channels Driven: 800W
• 4 ohms, Stereo Mode, Both Channels Driven: 1300W
• 2 ohms, Stereo Mode, Both Channels Driven: 2000W
• 70V 20Hz-20kHz +0/-0.3dB 0.5% THD: 1500W
• 8 ohms, Bridged Mono Mode: 2800W
• 4 ohms, Bridged Mono Mode: 4000W
• Rear panel gain controls for tamper resistant operation with 2 dB detents for quick and repeatable settings
• XLR and detachable Euro style input connectors
• DataPort V2 for use with DPV2-compatible signal processing accessories (XC-3, SF-3, LF-3) and DSP-3/DSP-4 (with external power supply)
• Independent defeatable clip limiters for reduced distortion
• Selectable high-pass filters protect speakers and prevent speaker transformer saturation with minimal effect on program material (30 Hz or 70 Hz)
• Front panel indicators include power, signal, and clip
• Covered barrier strip output connectors for safety agency compliance
• Automatic variable-speed fan for quiet normal operation with maximum cooling on demand
• Rear-to-front air flow keeps equipment racks cool
• Stereo, Bridge, or Parallel operating modes
• Comprehensive protection circuitry including DC, infrasonic, thermal overload and short circuit protection
• 3-year Manufacturers warranty plus optional 3-year extended service

Mic Wireless Sennheiser

Features:

• An affordable wireless handheld microphone system that provides you with amazing sound quality and reliable performance
• True Diversity reception provides you with worry-free operation
• 24 MHz switching bandwidth with 960 available frequencies, tunable in 25kHz steps
• 8 frequency banks containing 12 coordinated channels each
• Powerful scan function identifies available channels within a bank
• Component synchronization at a distance with Remote Channel sync for convenient onstage setup
• Up to 10 hours of operation with just 2 x AA batteries
• Up to 250′ of dropout-free transmission
• Illuminated audio mute button on transmitter make low-light operation easy
• Balanced XLR and unbalanced 1/4″ outputs for use with a wide range of equipment
• Operates in Sennheiser’s A band (548-572MHz)
